Proven Methods to Repair Corrupt and Damaged VMDK File

  • Written By

  • Updated on January 11th, 2025

Summary: A VMDK file is a virtual disk image file that stores virtual hard disk drive data. In the field of cloud computing and virtualization, these files play a crucial role. It is used to store the content of VMware virtual machines and competes with Microsoft. Although important, VMDK files are prone to corruption, which causes severe operational issues. However, repairing these damaged files can be challenging, often requiring specialized tools and methods to restore their functionality. In this blog, we outline straightforward methods to repair corrupt VMDK files using the VMware Data Recovery Tool.

User Query: How do I fix a corrupted VMDK file?

”An IT company uses VMware for virtualization and cloud computing. Their virtual machines show errors and are unable to boot up. After investigating, they found that their virtual disk was corrupted. ”

Reasons to Restore VMware Corrupt VMDK Data Files

  • Corrupting VMDK files results in the loss of considerable data.
  • Restoration of corrupted VMDK files ensures that operations are less disturbed and kept running.
  • Corrupted file restoration maintains the integrity and functionality of the VM.
  • Corrupt VMDK files can make virtual machines unusable. Restoration of these files minimizes downtime and ensures virtual environments remain accessible.
  • The system may be damaged further if VMDK files are not corrected. Restoring the files will help prevent further complications and data inconsistencies.
  • VMDK files usually contain sensitive data. Restoring these files ensures that sensitive information is protected and not permanently lost.

How to Restore the VMDK File in VMware?

There are various techniques available to restore a VMDK file in VMWare. Some of the techniques are mentioned below; check it for further updates:

  1. Manual methods to fix VMDK file corruption
  2. Restore the VMDK file with the help of the specialized tool

Manual Methods to Restore Corruption in VMDK Files

VMDK files are the virtual machine disk files, which contain all the data of the virtual machine and its disk contents. If these files get corrupted, they can cause downtime and data loss. Fortunately, you can recover corrupted VMDK files using various manual methods. Below is a detailed illustration of the technique you can use:

#1. Using VMware Workstation Recovery Mode

VMware Workstation has inbuilt tools that can recover a corrupted VMDK file:

Steps to Repair

  1. Open the VMware Workstation and select the VM that is affected.
  2. Now, right-click on the VM and select Settings. This will open the VM configuration window.
  3. Then, scroll down to the Hard Disk section and find the corrupt VMDK file.
  4. Now, click the Repair button.

This type of procedure takes place in instances where the corruption of files is partial and the tools can locate issues within the VMDK.

#2. Repair Corrupt VMDK File Using VMware vSphere Client (For vCenter Servers)

vSphere offers a much more sophisticated toolkit for managing and repairing VMDK files in environments operating VMware vCenter Server and ESXi hosts.

Steps to Repair

  1. Log in to the vSphere Client using your official administrator credentials.
  2. From the inventory, identify the affected virtual machine related to the corrupted VMDK file.
  3. Then, right-click the VM and then select Storage > Mount to try to mount the VMDK file to another VM.

This approach helps whenever VMDK corruption is coupled with issues about storage or the datastore within the virtualized environment managed by vCenter.

#3. Fix Corrupt VMDK File Using VMware’s ‘vmkfstools’ Command

The ‘vmkfstools’ tool offered by VMware provides functionalities that repair and manage virtual disk files, including VMDK files. This utility is useful for ESXi hosts.

Steps to Repair

  1. Connect to the ESXi host using SSH (you should enable SSH if not already enabled).
  2. After that, run the following command to fix the corrupted VMDK file:
vmkfstools -x repair /path/to/damaged.vmdk
  1. This utility scans and tries to repair any damaged blocks or metadata in the VMDK file.
  2. After the repair process is over, try to mount the VMDK once again to ensure that the virtual machine is functioning.

This command works for minor disk block corruption but may not work for complex corruption cases.

#4. Repair Corrupt VMDK File from VMware Snapshot

You can revert a virtual machine to a previous state using VMware snapshots. If a snapshot was taken before the corruption occurred, restoring it allows you to bypass the corrupt VMDK file and return the VM to a stable condition.

Steps to Restore

  1. Open the VMware vSphere or VMware Workstation interface on your system.
  2. Here, find the VM with the corrupted VMDK file and see if there are snapshots available.
  3. Then, right-click on the VM and choose the Snapshot option > Revert to Snapshot.
  4. In the end, VMware rolls back the virtual machine to the state it was in when you took the snapshot

Restoring a snapshot can be one of the easiest ways to recover if VMDK corruption has happened, but it requires that there exists a recent snapshot.

#5.  Converting the VMDK File

In cases where the VMDK file is severely damaged, you can sometimes attempt to convert the VMDK file to another format, such as VHD, using VMware’s VMware Disk Manager Tool. This tool allows you to convert the damaged VMDK file into a different disk format, which may help bypass some corruption issues.

Steps to Convert

  1. Open the VMware Workstation or use the VMware command-line interface on your defined system.
  2. Now, run the conversion command:
vmware-vdiskmanager -r /path/to/corrupt.vmdk -t 0 /path/to/new.vhd
  1. The `-r` flag is used to instruct VMware to repair and convert the VMDK file to VHD format.
  2. Once this process is complete, mount the VHD file to the virtual machine and check to see if the data is available.

This can be useful if your VMDK files have suffered major corruption and you need to recover the data in another disk format.

#6. Check and Repair Corrupt VMDK Files Using OS Utilities

Attach the corrupted VMDK file to a good VM and then use the disk utilities provided by the operating system to attempt repair.

Steps to Repair

  1. Firstly, attach the corrupt VMDK to a working VM as a secondary disk.
  2. Boot the VM and run the appropriate disk repair utility:

Windows uses `chkdsk`

chkdsk /f /r /x

On Linux, use `fsck`

fsck /dev/sdb1
  1. This utility will scan the file system for errors and attempt to repair them.

It works best in cases where corruption is more likely to be of the file system rather than a problem with the VMDK structure itself.

Repair Corrupt VMDK File With the Help of the Specialized Tool

The VMware Data Recovery Tool offers an efficient and easy solution for repairing corrupted or damaged VMDK files in VMware. Also, it makes use of a powerful recovery algorithm to restore the maximum possible data from corrupt VMDK files. The software supports various VMDK types, including fixed, dynamic, SPARSE, FLAT, and descriptor files. It is also compatible with popular operating system file systems, including FAT, FAT16, FAT32, FAT64, NTFS, HFS+, and EXT. Its RAW recovery mode makes it strong in dealing with seriously damaged VMDK files for total data restoration and minimal data loss.

Conclusion

This is a comprehensive write-up on how to repair corrupt VMDK files by describing the process and benefits. The manual technique of repairing the corrupt VMDK might look very simple, but it is not so. To apply the manual techniques, you have to have strong technical knowledge. Therefore, the best way to recover data from a damaged VMDK file is to use professional software like VMDK Recovery Software.
